Thrifty Flame Stop 'A' Aluminum Commercial Range Hood Grease Filter by Smith - 1" Thick

Extended handling time.

Buy a 2 pack and save, choose in the dropdown menu above.

Vertical dimensions are stated first, choose your size in the dropdown menu above.

Nominal Size (actual size 1/2” undercut on length and width, 1/8" undercut on thickness)

CONSTRUCTION The Thrifty Flame Stop filter is a unique roll-formed baffle filter, designed to prevent flame from penetrating through the filter, into the hood and duct work. The sturdy design is made of two layers of baffles, strategically placed to allow grease laden air to swirl, adhering the grease to the baffles themselves. Grease drains down the baffles into a trough, where it can be easily wiped away. Support strips hold each baffle at precise distances from one another, allowing the proper distance between each baffle as well as giving the Fire Patrol the stability this type of filter requires. Each baffle “pad” is supported by a solid metal frame, securely riveted on one side.

Maximum Temperature Range - 250 degrees F

Classified by U.L. (grease) NFPA std. 96

Low Resistance

Nominal Size (Actual size 1/2” under on LxW, slight undercut on thickness)

Custom sizes, handles, and spacers available, contact us with your needs for pricing.

Made in the USA

Due to possible materials shortages and unforeseen events, by ordering you consent to any handling time.
